Linear Systems XT-1 transmitter [inside view - note the DIP switches for settings, NC or NO control for input, etc] (see also XT-4 transmitter) 10 watt FSK transmitter operating on 27.255 MHz (US version) or 26.995 MHz (Canada version). When used with companion receiver(s) and other transmitter(s) can form the backbone of a data link or remote sensing and control system on the 26-27 MHz band using FSK modulation.
