Equipment / Re: Panaxis FME 500 issue
« on: August 09, 2018, 1607 UTC »
something i do in cases like this is use a can of "duster" upside down as "freeze spray" and a hair dryer as heat, both applied in small areas around the PCB and the components to narrow down the area of defect.
also, using the bristles of a tooth brush to "brush" and locate a component that may have become loose and the plastic end of the tooth brush to tap around the circuits/PCB looking for cold solder joints and loose components or connections.
this type of troubleshooting is performed with the unit on while watching to see if there are any changes in operation.
depending on where it was stored, if there was high fluctuations in temperature and humidity, there will be expanding/contraction of components/solder joints as well as electrolytics that may have "dried out" and adjustments fixed with wax that may have moved out of place.
im not sure if this unit used any of the component glue to stabilize the components to the PCB but lots of older electronics were severely plagued by this yellow glue becoming conductive when it dried out and turned a dark yellow or brown color.
also, using the bristles of a tooth brush to "brush" and locate a component that may have become loose and the plastic end of the tooth brush to tap around the circuits/PCB looking for cold solder joints and loose components or connections.
this type of troubleshooting is performed with the unit on while watching to see if there are any changes in operation.
depending on where it was stored, if there was high fluctuations in temperature and humidity, there will be expanding/contraction of components/solder joints as well as electrolytics that may have "dried out" and adjustments fixed with wax that may have moved out of place.
im not sure if this unit used any of the component glue to stabilize the components to the PCB but lots of older electronics were severely plagued by this yellow glue becoming conductive when it dried out and turned a dark yellow or brown color.
